Features
- The T Series programmable thermostat streamlines everything from product selection and installation to customer service and support
- With a standard footprint and simple interface, the T Series will enhance the entire thermostat experience for you and your customers alike
Specifications
-
Length: 4-1/16 in.
-
Width: 4-1/16 in.
-
Accuracy: 0.5C
-
Changeover: Automatic
-
Depth: 1-7/16 in.
-
Display Size: 5.45 sq-in.
-
Fan Current: 0.02A
-
Heat Current: 1A
-
Humidity Range: 5 - 90% RH Non-Condensing
-
Motor Type: UWP Mounting System
-
Power Source: Battery; Electric; Hardwired
-
Programmability: Programmable
-
Setting Temperature Range: 40 - 90 Deg F Heat;50 - 99 Deg F Cool
-
Stages: 2H/1C or 2H/2C
-
Switch Position: Heat-Off-Cool; Auto-EmHeat; Auto-On-Circ-Follow Schedule
-
Switch Type: Relay
-
Temperature Range: 37 to 102 Deg F
-
Terminal Designations: Rc, R, C, W, W2 - AUX, Y, Y2, O/B, G, K, E, L/A, S, S
-
Volts: 24V
-
Product Type: Thermostat
-
AMP: 1;0.05;0.02
-
Battery Size: AA
-
Colour/Finish Category: Whites
-
Colour/Finish Name: White
-
Control Type: Push Button
-
Maximum Temperature: 99
-
Style Name: T4 Pro
-
Origin: Mexico
-
Zones: 1
-
Height: 4-3/5 in.
-
Brand/Model Compatibility: Optional Outdoor Sensor C7089U1006 and Optional Indoor Remote Sensor C7189U1005
-
Installation Type: UWP Mount
-
Sensor Type: Thermistor
