Features:
• Absorbent Glass Mat Technology
• Valve Regulated, No-spill design
• Damage resistant ABS shell and seal
• 5 years design life in float service
• Suitable for UPS/EPS, medical equipment, emergency light and security applications
Certifications:
• UL Recognized
• CE Approved
• ISO 9001:2015 Quality Management Systems
• ISO 14001:2015 Environmental Management System
• ISO 45001:2018 Occupational Health and Safety Management System
Specifications:
Cells Per Unit: 6
Voltage Per Unit: 12V
Nominal Capacity: 7Ah @ 20 hour-rate to 1.75V per cell @ 25°C
Weight Approx.: 4.30 lbs. | 1.95 kg (Tolerance ± 5.0%)
Internal Resistance: ≤32m Ω (Full Charge Condition @ 25°C)
Terminal Default: F1, F2 Optional
Max. Discharge Current: 70A (5 sec)
Short Circuit Current: 350A
Design Life: 6 ~ 8 years
Max. Charging Current: 2.1A
Reference Capacity: C3 5.25Ah, C5 5.95Ah, C10 6.54Ah, C20 7.00Ah
Standby Use Voltage: 13.7V ~ 13.9V @ 25°C
Temperature Compensation: -3mV/°C/Cell
Cycle Use Voltage: 14.6V ~ 14.8V @ 25°C
Temperature Compensation: -4mV/°C/Cell
Operating Temperature Range: Discharge: -20°C ~ 60°C, Charge: 0°C ~ 50°C, Storage: -20°C ~ 60°C
Normal Operating Temperature Range: 25°C ± 5°C
Self Discharge: Actuvate Valve Regulated Lead Acid (VRLA) batteries can be stored for up to 6 months at 25°C and then recharging is recommended. Monthly self-discharge ratio is less than 3% at 25°C. Please charge batteries before using.
Container Material: A.B.S. UL94-HB, UL94-V0 Optional
